MINI3 - Keychain Flashlight

Trustfire MINI3 Keychain Flashlight

The MINI3 is a tiny keychain flashlight with a Wide Voltage Design which could be powered by 10440 or AAA battery (NiMH or alkaline) 1.2V/ 1.5V/ 3.6V/ 3.7V/ 4.2V and dual output settings ranging from 100 to 350 lumens. Turn on and off MINI3 keychain flashlight with a simple twist the head.

The MINI3 utilizes a CA18-3X LED, producing a maximum throw range of 108 meters.

Lightweight and tiny in size, the MINI3 is only 10g and 60mm or 2.36inch in length.  It can easily be attached to a keychain, handbag, or conveniently slide into a backpack or pocket.

PRODUCT SPECIFICATIONS

• Use one CA18-3X LED, Max 350 Lumen.
• With Wide Voltage Design which could be powed by AAA battery (NiMH or alkaline) 1.2V/ 1.5V/ 3.6V/ 3.7V/ 4.2V.
• Max runtime 1hour.
• Light range beam distance 108 Meters
• Aluminum alloy material, Wearproof, military grade III hard anodizing oxidation treatment.
• Max flood light beam angle of 170° and spotlight beam angle of 10°
• Easy to carry,Equipped with strainless steel pocket clip.  The detachable stainless steel pocket clip with scratch-resistant, corrosion-resistant coating makes it easy to attach to a bag, hat or backpack.

SIZE AND WEIGHT

• Length: 60mm
• Diameter: 14mm
• Weight: 10g(exclude battery)

MODES OF OPERATION

• Mode 1:screw the head,soft press the tail switch active high mode(just one mode)
• Mode 2:Unscrew the head for 25%,soft press the tail switch it will cycle through low-high.  Under mode 2,there is no memory function,every time switch on,it will go directly to high mode as default.

OUTPUT:
Power by a single 14500 battery
Mode 1: 350 Lumens (45 mins)
Mode 2: 10 Lumens (30 hours)

Power by a single AA battery
Mode 1: 150 Lumens (105 mins)
Mode 2: 3 Lumens (95 hours)

WATERPROOF

IPX8 waterproof to 2-meter for 30-minutes, 1-meter impact resistance tested.

TECHNICAL SPECIFICATIONS

BRIGHTNESS OUTPUTS
