H5 - Headlamp

The H5 is replete with thoughtful design touches, from the built in magnets in its endcap allowing you to hang the light from almost any metallic object, to its optional battery choices and housings that will ensure you're never left without a light.

When you add up the H5's swivelling body, mount, its 90 degree right angle head and other accessories, there is vitually no orientation that the H5 can't be positioned into to give you the best light in whatever condition you're in.

Whether you're running, hiking, or camping in the great outdoors, this little unit will not only light the way but stay out of your way, leaving you to focus and enjoy your activity to its fullest!

PRODUCT SPECIFICATION

• H5 features a shaft that can be rotated in 360 degrees
• Both the light tail and back clip features magnetic design, making it easy to attach H5 to a metallic surface.
• 400 lumens and a beam angle of 175 degrees
• H5 is compatible with 2A battery, and 14500 lithium-ion Battery

FEATURES

• Use the supplied 14500 920 mAh Li-Ion battery or regular AA battery (slightly reduced performance when using Alkaline type recommended)
• Waterproof and Dustproof
• Includes convenient head band accessory for mounting the light up and out of the way
• 360 degrees of rotational positioning adjustment
• Multiple magnetic mounting options
• Lockable clip for hands-free use

MODES OF OPERATION

• H4 has a multi-functional 6 lighting modes: Turbo, High, Medium, Low, Moon and SOS
• Turbo output mode: 400 lumens;73m beam;runs 10 minutes
• High output mode: 200 lumens; 73m beam; runs 1.5 hours
• Middle output mode: 150 lumens; 45m beam; runs 3 hours
• Low output mode: 50 lumens; 26m beam; runs 7 hours
• Moonlight output mode: 1 lumens; 4m beam; runs 120 hours
• Strobe mode: 150 lumens

CHARGING

• The included 14500 Li-Ion battery features a protected circuit, and can be charged directly using the supplied USB cable.

POWER LEVEL INDICATOR
Features a battery indicator located on the side switch , once the light is under OFF status, soft press the button to know realtime battery:

• Constant Blue (Battery Capacity > 90 %)
• Flashing Blue (90% > Battery Capacity > 40%)
• Red (40% > Battery Capacity > 15%)
• Flashing Red (15% > Battery Capacity > 0%)

SIZE AND WEIGHT

• Length: 72 mm
• Diameter: 23.8 mm
• Weight: 43 g (excluding battery)

BATTERY SUPPORT

• H5 support 3.7V Li-ion 14500 Protected Circuit, AA Ni-MH and AA Alkaline batteries.

WATERPROOF

• IP68 waterproof to 2-meter for 1 hour.

PACKAGE INCLUDES

• H5 Headlamp x 1pcs
• 14500 Li-Ion Rechargeable Battery x 1pcs
• USB Type A to Type C Charging Cable x 1pcs
• Spare O-Ring Seals x 1pcs
• Head Band x 1pcs
• Hand Lanyard Strap x 1pcs
• Instructions x 1pcs
• USB Power Adapter not included

TECHNICAL SPECIFICATIONS

BRIGHTNESS OUTPUTS
